External Dimensions: 2382 × 1134 × 30 mm
Weight: 28.1 kg
Solar Cells: N-type Topcon Mono 105 × 182 mm (132 pcs)
Front Glass: 3.2 mm AR coating tempered glass, low iron
Frame: Anodized aluminium alloy
Junction Box: IP68, 3 diodes
Output Cables: 4.0 mm², 300 mm(+) / 200 mm(−) or Customized Length
Mechanical Load: Front Side Maximum Static Loading 5400Pa
Rear Side Maximum Static Loading 2400Pa
